Thermal Camera MLX90640-D55 IR Array Thermal Imaging Camera,I2C Interface 32 * 24 Pixel Infrared Array,55 Degree Field of View

Overview: Thermal Camera MLX90640-D55 is a far-infrared thermal sensor array designed with MLX90640. With a resolution of 32*24, it provides great performance for applications that do not require high-resolution images or high frame rate, and provides a cost-effective alternative to more expensive high-end infrared thermal camera. Typical applications for the MLX90640 include fire protection systems, intelligent buildings, Intelligent lighting, IP/surveillance cameras, HVAC equipment and vehicle seat occupancy detection. This product provides demo codes intended for Raspberry Pi platform. The demo codes is divided into C and python versions, both of which include thermal image display function. Specifications: Dimensions:20mm(length)*18mm(width) Resolution:32*24 Refresh Rate:0.5Hz~64Hz Field Of View(FOV):55°×35° Communication Interface:I2C Supply Voltage:3.3V/5V Working Current:<23mA Operating Temperature:-45~85℃ Temperature Measuring Range:-40℃～300℃ Absolute Accuracy:±2℃ Package contents: 1.Thermal Camera MLX90640-D55×1 2.PH2.0 4PIN wire×1

• 1.Small size, low power consumption, 32*24 pixel infrared array,55°field of view
• 2.I2C interface communication, the highest speed can reach 1MHz
• 3.Compatible with 3.3V/5V working level
• 4.Noise Equivalent Temperature Difference (NETD) is 0.1K RMS @ 1Hz refresh rate
• 5.Available for open development resources and tutorials which are intended for Raspberry Pi Development Board
